TECHNOLOGY
Print Technology
Inkjet, Océ drop-on-demand, piezoelectric
Ink
Océ proprietary, water-based pigment ink
Drop Size
Variable, Multi-level
Print Speed
300 A4 images / 152 A3 images duplex
150 A4 images / 82 A3 images simplex
Specialty Speed
200 A4 images / 106 A3 images duplex
150 A4 images / 82 A3 images simplex
Duty Cycle
1,000,000 - 10,000,000 A4 impressions/month
Print Resolution
600x600 dpi with multilevel (1200 dpi perceived)
Paper Weight
60-300 gr/m²
Substrates
Uncoated, inkjet treated and inkjet coated
PAPER
Paper Weight
60-300 gr/m²
Substrates
Uncoated, inkjet treated, inkjet coated, offset uncoated, offset coated, tabs
Standard Configuration
1 Paper Input Module (PIM), Standard PIM or PIM-XL
1 High Capacity Stacker
Optional
Second and third Paper Input Module, Standard PIM or PIM-XL
Second High Capacity Stacker
Paper Sizes
203 x 203mm - 488 x 320mm
178 x 254mm (with optional guide)
350 x 500 mm or 353 x 500 mm with PIM-XL
Paper Capacity
4,600 sheets A4 (80 gsm) with one PIM
9,200 sheets A4 (80 gsm) with two PIMs
13,800 sheets A4 (80 gsm) with three PIMs
STANDARD PAPER INPUT MODULE (PIM)
Paper Trays
2 x 600 sheets, 2 x 1,700 sheets (80 gsm)
Standard Paper Capacity
4,600 sheets
Paper Size
203 x 203 mm - 488 x 320 mm
178 x 254 mm (with optional guide)
Dimensions (WxDxH)
987 x 1015 x 1040 mm
Weight
240 kg
PAPER INPUT MODULE XL (PIM-XL)
Paper Trays
2 x 600 sheets, 2 x 1,700 sheets (80 gsm)
Standard Paper Capacity
4,600 sheets
Paper Size
Top tray: 203 x 203 mm - 488 x 320 mm
All other trays: 350 x 500 mm or 353 x 500 mm (fixed)
Dimensions (WxDxH)
987 x 1015 x 1040 mm
Weight
240 kg
HIGH CAPACITY STACKER
Stacks
2 x 3,000 sheets (80gsm) per stacker
Dimensions (WxDxH)
899 x 745 x 1040 mm
899 x 1250 x 1040 mm with stack tray ejected
Weight
Empty 140 kg, full 300 kg
PRISMASYNC CONTROLLER
Network Connectivity
2 x 10 gigabit Ethernet (10/100/1000 Base-T)
TCP/IP (LPR /LPD, 9100 Socket), Static IP / Auto-IP (DHCP), IPv4,
IPv6 (only in Document Printing mode)
Page Description Languages
PDF 1.7 (Extension Level 3), PDF-X (APPE 3.x RIP support), PDF/VT (Level 1), PPML, IPDS IS/3
Job Submission
lpr, Hotfolders via WebDAV, Socket (streaming), JDF/JMF (via adapter), IPP 2.0
Protocols
SNMP v1, SNMP v3, Host Resources MIB, MIB II, Printer MIB, Job Monitoring MIB, Job Management MIB (partially)
Spot Color Libraries
PANTONE+ Solid (Coated & Uncoated), PANTONE GOE (Coated & Uncoated), HKS (K,N), HKS (K,N) 3000+, PANTONE+ Solid 336 New (Coated & Uncoated)
CONNECTION REQUIREMENTS
Connection Fuse (EU)
230/400 VAC, 100A; 100-240 VAC, 13-20A; 200-240 VAC, 13-20A
Power Consumption-Printing (EU)
22 kW
Power Consumption-Idle (EU)
13.5 kW
Compressed Air
8-12 bar, dry and oil free
Tap Water
Maximum 8 bar pressure, 1 - 40°C
ENVIRONMENTAL
Temperature
Optimal range 20-26 °C
Humidity
Optimal range 30-50%
Operating Noise
Printing 71 dB, Standby 61 dB
PHYSICAL DATA*
Length × Width x Height
8,800 × 2,750 x 2,400 mm
Weight
Approximately 7,000 kg
Αποποίηση ευθυνών
* Physical data is provided for a standard configuration which includes one PIM and one High Capacity Stacker
